Intelligy – System Overview

overview image 1

overview image 2

overview image 3

overview image 4

Intelligy Demand Response Enabling Device (DRED) provides Utility Companies the ability to remotely initiate Demand Response Modes on high consumption equipment such as air-conditioners (thermistor temperature controlled) pool pumps and water heaters.

DRED

Intelligy Display

Intelligy Power Monitoring Switch (PMS) allows the monitoring and management of individual connected appliancs back to the Intelligy Display (ID).

Intelligy Power Monitoring Switch (PMS)

Intelligy Power Monitoring Device (PMD) monitors the consumption of fixed appliances (pool pumps etc) and relays information back to the ID.

Intelligy Power Monitoring Device (PMD)

Intelligy GPRS Module

Intelligy GPRS Module provides internet connectivity for the ID and the HAN. Appliances can be controlled remotely on any web-enabled device.

Intelligy Serial Communication Module

Intelligy Serial Communication Module allows equipment like solar invertors to be connected to the Home Area Network (HAN) and the ID. The display will show power consumed and power generated.
